DT-856/856A
Light Meter with PC Interface
DT-856 light meter provides accurate display light level in terms of Foot Candles FC or LUX over wide range. Just turning the Function Switch to select the “lux” scale and setting the range to desired range, then removing the photo detector to light source in a horizontal position and reading the illuminance norminal from the LCD display. When the measurement is completed, replace the photo detector from the light source.
DT-856A LED light meter, measures light from visible luminaries equipped with white light LED, fluorescent, meatal halide, high-pressure sodium and incandescent sources.
DT-856 light meter provides accurate display light level in terms of Foot Candles FC or LUX over wide range. Just turning the Function Switch to select the “lux” scale and setting the range to desired range, then removing the photo detector to light source in a horizontal position and reading the illuminance norminal from the LCD display. When the measurement is completed, replace the photo detector from the light source.
DT-856A LED light meter, measures light from visible luminaries equipped with white light LED, fluorescent, meatal halide, high-pressure sodium and incandescent sources.
| Features |
| ۴۰۰۰ Counts LCD dual display with timer function |
| Auto Ranging |
| Max./Min. and Data Hold |
| Auto Power Off |
| Low battery indication |
| User selectable FC/Lux |
| Capacity for data logging (99 readings) |
| Total accuracy: for C.I.E standard illuminate A (2856K) |
| Specifications | DT-856 | DT-856A |
| Measuring range | ۴۰۰,000Lux | ۴۰, ۴۰۰, ۴۰۰۰, ۴۰۰۰۰, 400000Lux ۴۰, ۴۰۰, ۴,۰۰۰, ۴۰,۰۰۰, FC |
| Accuracy | ±۵%±10d (<10,000Lux) ±۱۰%±10d (>10,000Lux) | ±۳% (Calibrated to standard incandescent lamp 2856 o K and corrected LED day while-light spectrum). +/-6% other visible light source. |
| Max Resolution | ۰.1Lux/0.01Fc | ۰.01Lux/0.01Fc |
| Light Source Selecting | \ | Tungsten/Daylight, Fluorescent, 0~9 select rating |
| USB interface | * | \ |
